Manufacturing

Sl. No.

Machine Name

Make

 Capacity

Blanking Machines

1

CNC Profile Cutting Machine With Plasma & Oxy - Fuel Torch

Pro Arc Welding

45 Mm / 200 Mm.

2

Shearing Machine Pneumatic Type

Hydra Sherar

8 Mm

3

Hyd. Cutting  Machine

Kwality

12.5 Mm

4

Band Saw Cutting

Mirinda Tools

300 Mm

5

Band Saw Cutting

Multi Cut

300 Mm

6

Double Column Band Saw Cutting

Itl

450 Mm

7

Band Saw Cutting

Awal

250 Mm

8

Band Saw Cutting

Awal

250 Mm

CNC Vertical Milling Center Machines

1

VMC  Milling  Center ( 3 Axis )

Dahlih

X=500mm,Y=300mm,Z= 510mm

2

VMC  Milling Center (5 Axis)

BFW

X=825mm,Y=510mm,Z= 510mm 4th And 5th Through Rotary Table

3

3- Axis CNC Double Column Machine Centre Model Spm2215 With Horizontal Milling Attachment

Jyoti

Useful Surface (X – Y-Z )                                             2200 X 1800mm X 1000mm

CNC Horizontal Milling Center

1

4- Axis Double Pallet Horizontal Milling Center

Toyoda

Traverse ( X-Y-Z-C)                                         600mm X 600mm X 560mm X 500mm

CNC Turning Center

1

CNC Turning Center

HMT

 Chuck Dia 300mm X 2500 Mm

2

CNC Turning Center

Daewoo

Chuck Size 250 X 1000 Mm

3

CNC Turning  Center

Shoun Dynastar 400

Chuck Size 250 X 1000 Mm

4

CNC Turning  Center

PMT

Chuck Size 200 X 500 Mm

CNC Turn Mill Center

1

CNC Turn Mill Center

Jyoti

 Dia 250mm X 700mm X C Axis +/- 90 Degree

Pipe Bending and Flaring Machines

1

CNC 3 Axis Pipe Bending Machine

Electropneumatics

Dia 10 Mm To Dia 80 Mm

2

Hydraulic Pipe End Flaring Machine

Hydrotech

Max 20 Mm

ZIG Boring Machine

1

ZIG  Boring  Machine

Societe (Sip) Genevoise

X=1000 Mm.,Y=600 Mm, Z= 800 Mm

Grinding and Honning Machine

1

ZIG Grinding Machine

Catmor

550mm X 310mm

2

Internal  Grinding

Jung  Berlin

500 Mm

3

Surface  Grinding

Mostana

1000 Mm X 500 Mm X 400 Mm

4

Surface  Grinding

Univishp-32/ Vacvolne

450 Mm X 150 Mm X 150 Mm

5

Center-less Grinding

Rita  India

125 Mm

6

Tool & Cutter Grinder

Abl.S.Thorn

25 Mm

7

Cylindrical  Grinding

Tos  Hostivar

L=600mm, Dia 100 Mm

8

Cylindrical  Grinding

Amba  Petlar

L=600mm,Dia 100 Mm

9

Cylindrical  Grinding

Tos  Hostivar

L=1000mm, Dia 500mm

10

Honning  Machine

Delapena Speed Hone

Heat Treatment Furnaces

1

Electrically Heated Chamber Type  Furnace With Temperature Controller And Recorder

Simplicity

500 Mm X 500 Mm X 400 Mm

2

Electrically Heated Tempering Furnace With Temperature Controller And Recorder

Simplicity

Internal Dia 1000 Mm, Depth 1500 Mm

3

Electrically Heated Bogie Type Stress Relieving Furnace with Temperature Controller And Recorder

Aditya Thermal

W 1000 Mm X L 1500 Mm X H 1000 Mm

Press Machines

1

Hydraulic Press Break

In-house

800 Tonne

2

Hydraulic Screw Press Break

Birson

50 Tonne

Conventional Machines

1

Lathe Machine

HMT and Imported Make Qty. 50 Nos.

3 mtrs X 1200 mm to different sizes

Fabrication  Group

1

Power  Hexa  Saw Cutting

Mt

6 Inch Od

2

Radial Drill Machine

Tested

1.77  Inch

3

Power  Press  Machine

Birson

50 Ton

4

Press(Screw)

Birson

100 Ton

5

Drill  Machine

Mew

1 Inch

6

Hydraulic Press Machine

Birson

1 Ton

7

PLP Cutting Machine

Techno Eng.

9 Mm

8

Ball  Ending Machine

Techno Eng.

9

Press Machine

Sew

25 Ton

10

Horizontal Testing  Machine

125 Ton

Fabrication and welding

1

Arc Welding Machine

Ador, Esab and other make Qty. 20 Nos.

400 to 600 Amps

Aluminium Casting

1

Oil Fired furnace-I With Temp Controller And Recorder

225 Kg

2

Oil Fired Furnace-Ii With Temp Controller And Recorder

225 Kg

3

Oil Fired Furnace-Iii With Temp Controller And Recorder

225 Kg

4

Oil Fired Furnace-Iv

60 Kg

5

Oil Fired Furnace-V

40kg (Gunmetal)

6

Mobile Auot Degassing Unit

Galaxy

7

Reduced Pressure Tester

Furdonjee

Electro Plating Section

1

Electro Zinc Plating & Yellow Passivation

In House

2

Electro Hard Chrome Plating

In House

Hot Dip Galvanize

1

Complete set with Temprature Controler and EOT

In House

2500 X 1250 X 1000 MM
