Testing

S. No.

Description

Specification

1

ATOS Compact Scan 2M optical blu light scanning system with 64 BIT Hardware calibration object 500X380

3D Scanner and Image Anaylsis

2

Profile Projector with Digital Data Processor Model: PB-12AZ

Magnification: 10X
Work stage: 350 X 250 mm
Travel: 200 X 100 mm Screen dia: 300mm          Angle reading: 360 degree

3

Spectro meter

Chemical Analysis

4

Surface Roughness Tester

Surface Roughness

5

Hardness Tester (Ball Rebound Type)

HRC, BHN, HLD

6

Brinell Hardness Tester

BHN

7

Rockwell Hardness Tester

HRC

8

Kelvin    Double    Bridge    (for    low    Resistance measurement)

0.2 Micro Ohm to 11 Ohm

9

Load Cell with indicator

5, 10, 15 & 50 Ton each

10

Chemical Laboratory duly equipped with Metallurgical Microscope with image analyzing software and digital camera

for measuring the Bonding strength & Chemical reaction of metals

11

Metallurgical   Microscope   with   image   analyzing software and digital camera

100x magnifier with image analyzer

12

Electro Dynamic Shaker

200 Kgf (for Damper Vibrator Test)

13

M.P.I.

Model - unimag WCH 206 M

14

M.P.I.

Model-UNIMAG UCH-410

15

Horizontal UTS/Proof Load Testing machine

100 Ton Capacity

16

Digital Thick Coat Meter

for measurent of thickness of coated

17

Hydraulic Compressing Machine including 4 Nos. of Dies

150 Ton

18

Magnetic Power Loss Test Set-up

3000A

19

Heating Cycle Test Set-up

250 Cycle

20

36 Meter Vibration Test Span

21

Go and Nogo Gauge Ball 20 mm

As per IS:2486 (part-II)

22

Go and Nogo Gauge Socket 20 mm

As per IS:2486 (part-II)

23

Go and Nogo Gauge Ball 16 mm

As per IS:2486 (part-II)

24

Go and Nogo Gauge Socket 16mm

As per IS:2486 (part-II)

25

Vertical  UTS

60 Ton Capacity

26

DIP Test

for measurent of thickness of coated zinc

27

Duck Spacer Testing Machine

28

Rubber Tensile Testing Machine

 Tensile Testing Machine
